Weird std::thread bug on GCC 4.9 on ARM target

I have been dealing with Tizen development since about last year, and since then I have been learning of utilizing C++11 features on my codes. Currently I am developing a some kind of component to help performing message pump in threading, so you can dispatch a function to a queue to be performed in separate thread.

It is a simple components actually. You can take a look at GitHub. DispatchQueue class basically accepts functions to be queued to be executed in another thread. I uses std::deque to queue the tasks, and std::function to store lambda or other callable objects. To support the threading, I uses std::mutex for synchronization, as well as std::condition_variable to suspend thread during empty queue.

The code compiles flawlessly, but when I tried to run a Tizen native app using this component, the app directly crashed upon starting the DispatchQueue class. The worst part was that the call stack in crash log does not show that it was crashing in user code, but it shown that the signal was SIGABRT so it might be caused by an unhandled exception.
Continue reading “Weird std::thread bug on GCC 4.9 on ARM target”

GPS Library for Windows 10 IoT and Raspberry Pi

I am tinkering with Raspberry Pi 3 (RasPi) and Windows 10 IoT Core. I was thinking how to build an IoT device with GPS functionality in RasPi. Many IoT projects employ GPS module but they use it mostly with Arduino to build quadcopter. Some people tried it with RasPi, but they use it in Raspbian OS. No one seems tried to build directly with RPi and Windows.

So, I made my own implementation, a library to connect Windows apps with GPS device. Long story short, you can make Windows app running on RasPi which utilize GPS, and you can code it on C#.

Check the code on GitHub. The library is licensed under GNU Lesser General Public License v3. You may use it in your project while retaining the license and credit to me. 🙂

How To Use

You just simply to download the binary release, or compile it on your own. Then add reference to Heliosky.IoT.GPS.dll in your project.

To use the library, you can add usings below to simplify the class resolution.

Continue reading “GPS Library for Windows 10 IoT and Raspberry Pi”

(Almost) Seamlessly Integrate Android Layout XML to Code Behind Reference

It’s been a while since my last post. With this post, I would like to share a little bit of my toolkit which I use extensively on my Android project. 🙂

Overview

So basically, when you are developing apps for Android, you use Android XML file to define the User Interface (UI) layout structure, then you code using Java for the implementation. Basically they resembles the .NET WPF/Silverlight’s XAML development, which they also use XML file to define the UI layout. But the worst thing I hate in the Android implementation is that basically the XML file and the Java code behind doesn’t really integrated seamlessly.

What made me say that .NET XAML is far years ahead compared to Android XML layout file? See the difference between those two frameworks below. Example: I want to make a simple WPF application containing a text box and a button. The button will be set disabled immediately after clicked, and show message box containing the text in the text box.

NET Framework WPF

In .NET Framework, the XAML file is seamlessly integrated with the code behind. In XAML you can define a Name for each of your control (widget), and call it directly from the C# code behind using the defined name

XAMLC#

<Window x:Class="LatianWPF.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        Title="MainWindow" Height="350" Width="525">
    <Grid>
        <TextBox
             x:Name="TextBoxA"
             HorizontalAlignment="Left"
             Height="23"
             Margin="10,10,0,0"
             TextWrapping="Wrap"
             Text="TextBox"
             VerticalAlignment="Top"
             Width="497" />

        <Button
            x:Name="ButtonB"
            Content="Button"
            HorizontalAlignment="Left"
            Margin="432,38,0,0"
            VerticalAlignment="Top"
            Width="75"
            Click="ButtonB_Click" />

    </Grid>
</Window>

public partial class MainWindow : Window
{
    public MainWindow()
    {
        InitializeComponent();
    }

    private void ButtonB_Click(object sender, RoutedEventArgs e)
    {
        ButtonB.IsEnabled = false;
        MessageBox.Show(TextBoxA.Text);
    }
}

Android

To perform the same task in Android, you have to call findViewById for each widget ID defined in the XML layout file, and cast and store the returned value from the function call to the instance variable. This leads to messier code compared to .NET style, because you have to call and assign every reference in code behind before you can access what is defined inside XML layout file. Basically you do the integration between XML layout file and code behind manually.

Android XMLJava
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/listitem_bill_root"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    tools:context="${packageName}.${activityClass}" >

    <EditText
        android:id="@+id/main_editText1"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:ems="10" >
    </EditText>

    <Button
        android:id="@+id/main_button1"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Button" />

</LinearLayout>

public class MainActivity extends ActionBarActivity implements View.OnClickListener {
	private Button button1;
	private EditText editText1;

	@Override
	protected void onCreate(Bundle savedInstanceState) {
		super.onCreate(savedInstanceState);
		setContentView(R.layout.activity_main);

		this.button1 = (Button)findViewById(R.id.main_button1));
		this.button1.setOnClickListener(this);

		this.editText1 = (EditText)findViewById(R.id.main_editText1));
	}

	@Override
	public void onClick(View v) {
		button1.setEnabled(false);
        Toast.makeText(this, editText1.getText(), 10000);
    }
}

Idea

I want Android to have similar capability like .NET Framework which I don’t have to assign the reference to the widget manually by calling findViewById on each widget. This is to simplify the code and to make the code cleaner.

Implementation

Continue reading “(Almost) Seamlessly Integrate Android Layout XML to Code Behind Reference”

Using Generics in an Ugly Way

Previously I was talking about generics. You can see how I do with generics to the confusing level:

new AsyncTask<Void, Void, RefreshTaskResult<ActionResult<List<SquadInfoShort>>>>() {
	protected RefreshTaskResult<ActionResult<List<SquadInfoShort>>> doInBackground(Void... params) {
		try {
			ActionResult<List<SquadInfoShort>> result = client.getSquadList();
			return new RefreshTaskResult<ActionResult<List<SquadInfoShort>>>(result);
		} catch (Exception e) {
			// Catch any exception
			return new RefreshTaskResult<ActionResult<List<SquadInfoShort>>>(e);
		}
	}
}.execute();

See how many < > to feast your eyes.

Generics in WCF REST JSON Communication

Overview

So I got a task in designing a scalable and modular Service Oriented application using JSON and WCF. I am designing a web service using WCF. The communication between the web service and the client will be using JSON. While the server is using .NET Framework, the client is using Android Java. I aim to design the service as modular as possible. For every web service request from the client, the server will return the response in some kind of “envelope”. The “envelope” contains the execution result, whether it is success or not, the text message from web service, and the attachment which may contains object of specific type as the result of the service call.

I want to develop the modularity in my service framework, where I can make the “envelope” object as generic object that accept any kind of attachment type. And I want to deserialize the JSON response from server in my Android directly into specified “envelope” and attachment type, so that I can use it fairly easy in my code.

Prerequisite

Continue reading “Generics in WCF REST JSON Communication”

Entity Framework: Design Approach

I’ve been using Entity Framework since its introduction. Entity Framework (EF) is a powerful Object-Relational Mapping (ORM) framework for .NET Framework. I’ve been debating with my teammates whether EF is better than other ORM such as OpenAccess, which I believe is true, because EF provides the necessary feature to connect our program to the database, especially if you are using Microsoft products, SQL Server. In my thinking, why bother using custom ORM to connect to SQL Server while actually Microsoft, the creator of everything (well, not, only .NET Framework and SQL Server I’m talking about here) provided the powerful tools to support your needs. In fact, Microsoft fully support the EF and provides the latest features as their development (EF and SQL Server) (should) inline each other.

Ok, I’m not going to debate about which one is better. I am going to talk about Code First approach to build your model from scratch. This is the first time I am trying using Code First approach, while previously I always use Database First or Model First approach.

Ways to Model Your Database

Entity Framework has been evolving quite rapidly. In the newest version, I noticed they are now using DbContext class instead of the old ObjectContext. And the new generated classes (if you are generating the model from existing database), will be just Plain-Old-CLR-Objects (POCOs). In previous EF, all the model classes must be derived from EntityObject. This offers more flexibility in designing your model classes.

One other notable changes I found is that the entity framework do not require the resource file definition in the connection string anymore. This will offer more flexibility in porting your model into separate DLL library and reuse it wherever you want. I am going to explore this finding later.

So to model your database, you can use three different approach: Database first, Model first, or Code first. Below is the explanation of each one of the way
Continue reading “Entity Framework: Design Approach”

Story of Modularity: Loading XML Files

Previously I told about achieving modularity in web application and I mentioned about using XML files as a configuration script for our module. This session, I’m going to explain the easy way to load external XML file to your program. This method doesn’t only work on web application, but in any .NET application.

Where to Start?

I usually start developing custom XML structure by typing directly to my XML file. It is some kind of prototyping your XML structure. In this case, I am going to develop an XML file that contains a configuration information for my modular theming system. The XML file will describe the theme description and theme structure which is a list of ASPX pages that is inside that theme file. For each pages in theme, they should contains the type of the page, title of the page, identifier, and ASPX file name of the page.

From that requirement, I could derive my new theme file is something like this:

Continue reading “Story of Modularity: Loading XML Files”

Story of Modularity: Achieving Modularity in Web Application

In my Heliosky.Story project, I am planning to create modularity on every part of the system. To achieve modularity, my program has to be able to load module or application part dynamically. Achieving modularity in web programming is not an easy task. Basically I am amazed with WordPress style of modularity, where they provide a full set of modular API so you can easily develop your custom theme, page, or plug-in in a logical manner. As we know, WordPress is built on top of PHP, a scripting language. Every module or application part in WordPress is a PHP script.

Continue reading “Story of Modularity: Achieving Modularity in Web Application”

Control Your Source Code

You usually save your code on your development machine. When you need to share your code with your friend, or perhaps when you use multiple development machine such as desktop and laptop simultaneously, you share your code by copying the entire folder and share it to your liking. This is a very bad practice, especially when sharing involves changes and development from other party. Because of that we need a Source Control system.

So my friends, what is source control? Basically it is a software that controls the changes and revisions on each line of your source code. So every changes are tracked, every files in your software project are monitored, and it has revision history so you will never lose track with any changes happen on your source code. They say that source control only useful for large projects, I say NO! Source control is very useful for any collaboration between two people. Even I, the lonesome programmer, can really make use the benefit of source control system so that I can keep my development workstations, my desktop and my laptop, in sync.

Okay, so I need to find a source control system that is suitable for me. The main requirement for my source control system is: CHEAP, preferably FREE. I was searching for the best solution for me. So I travelled the journey to look for the best. Here’s the story of my journey.

Continue reading “Control Your Source Code”

How To Hack Your (Friend’s) Windows 7 Password

DISCLAIMER – The purpose of this post is to show how vulnerable Windows 7 is. The writer disclaim all the charges for any damages caused by this post. You MUST address the claim to Microsoft® for developing such a bad security on their operating system.

Recently I just told that I could hack the password on Windows 7 by the infamous NET command from command prompt. I tried it when I’m on Samarinda last sunday when configuring the laptop for computer training participant. It failed. I was told using NET USER command from the command line console in Windows Recovery Tools. I found it very ridiculous which the NET USER commands return the users on the Windows 7 installer environment, which are Administrator and Guest only. It is not linked to the Administrator account on your installed Windows on your hard drive.

While today, when I consider that “myth” is busted, my friend Ken Danniswara told me that that is not how you do it. You use the recovery command line console to perform some “magic” trick to Windows system files, before you can actually hack a password in less than 10 minutes. And then he explained to me how he performed it. So here it is:

Continue reading “How To Hack Your (Friend’s) Windows 7 Password”
